KickAss 12V 50A Manual Reset Circuit Breaker
KickAss 12V 50A Manual Reset Circuit Breaker
SKU:KACB50P
A high quality, circuit breaker for your dual-battery setup. Provides complete protection from over-voltage. Both dust and water proof, so able to withstand the harshest conditions.
Specifications
Specifications
| Size | 87mm x 49mm x 45mm (L x W x H) |
| Material | Thermoplastic, IP67 fully sealed, ignition protected |
| Current | 50Amp @ 48VDC Max |
| Voltage | 12V |
| Mechanism | Thermal trip with indicator, manual trip button |
| Mounting | Wide surface mount |
| Pole | Single Pole, normally closed |
| Stud Size | 1/4" (uses 6.3mm ring terminals) |
| Compliance | SAEJ1625:ABYCE, SAE J1117 (Ignition Protected) |
| Weight | 0.109kg |
User Manuals
User Manuals
Australia Wide Online Store
View the full range
Australian Retail Stores
Visit one of our retail locations across Australia
New Zealand
Call our New Zealand Distributor
KICKASS® Hi-Amp 50A Manual Reset Circuit Breaker
The Hi-Amp style circuit breakers provide ultimate protection for dual battery systems and high DC current electrical circuits. Rated at 50A with an IP67 rating, they are sealed against moisture, dust, and dirt, and are ignition protected—making them perfect for under-bonnet applications in serious off-road vehicles. Also suitable for industrial, agricultural, and marine use.
Equipped with a trip indicator and manual trip button, these breakers are easy to reset with a simple push of the tab. Built with a robust surface mounting frame and two 1/4" stainless steel studs for solid cable connections.
If you need a dependable, high-quality circuit breaker for demanding dual battery setups, the KICKASS® Hi-Amp style breaker is the ideal choice.
